Control Cable

This product is suitable for control circuits with a rated AC voltage of 450/750 V or below, and complies with the requirements of the GB/T 9330-2020 standard, *Plastic Insulated Control Cables*.

+86 198 6198 9573

+86 198 6198 9573

Anita@frt-electric.com

Get A Quote

Related Product

Product Description

PVC-Insulated Control Cable

This product is suitable for control circuits with a rated AC voltage of 450/750 V or below, and complies with the requirements of the GB/T 9330-2020 standard, *Plastic Insulated Control Cables*.

Operating Characteristics and Key Electrical Performance Specifications

1. The minimum installation temperature for the cable is ≥ 0°C.

2. The maximum permissible long-term operating temperature for the cable conductors is 70°C.

3. Minimum permissible bending radius:

a: For unarmored cables, it shall be no less than 6 times the cable's outer diameter.

b: For cables with armor or copper tape shielding structures, it shall be no less than 12 times the cable's outer diameter.

c: For flexible cables with shielding structures, it shall be no less than 6 times the cable's outer diameter.

4. The finished cable shall be capable of withstanding an AC voltage withstand test of 3000V at 50Hz for 5 minutes without breakdown. The DC resistance of the conductors shall comply with the requirements specified in the standard GB/T 3956-2008, *Conductors of Cables*.

5. Cable model, designation, and installation environment.

Cable Model, Name, and Installation Environment

Model	Full Name	Application Scenarios
KVV	Copper Core PVC Insulated PVC Sheathed Control Cable	For fixed installations indoors, in cable trenches, ducts, etc.
KVVP	Copper Core PVC Insulated PVC Sheathed Copper Wire Braided Shielded Control Cable	For fixed installations requiring shielding indoors, in cable trenches, ducts, etc.
KVV22	Copper Core PVC Insulated PVC Sheathed Copper Tape Shielded Control Cable	For fixed installations requiring shielding indoors, in cable trenches, ducts, etc.
KVV23	Copper Core PVC Insulated PVC Sheathed Steel Tape Armored Control Cable	For fixed installations with high mechanical stress indoors, in cable trenches, ducts, direct burial, etc.
KVV32	Copper Core PVC Insulated PVC Sheathed Fine Steel Wire Armored Control Cable	For fixed installations with high mechanical tensile force indoors, in cable trenches, ducts, vertical shafts, etc.
KVVR	Copper Core PVC Insulated PVC Sheathed Flexible Control Cable	For applications requiring flexibility and movement indoors.
KVVRP	Copper Core PVC Insulated PVC Sheathed Copper Wire Braided Shielded Flexible Control Cable	For applications requiring flexibility, movement and shielding indoors.
KVVP2-22	Copper Core PVC Insulated PVC Sheathed Copper Tape Shielded Steel Tape Armored Control Cable	For fixed installations with high mechanical stress and requiring shielding indoors, in cable trenches, ducts, etc.

Production Scope

Model	Rated Voltage (V)	Conductor Nominal Cross Section (mm²)	0.5	0.75	1.0	1.5	2.5	4	6	10
		No. of Cores
KVV / KVVP	450/750		-	2-37	2-37	2-37	2-37	2-19	2-19	2-10
KVVP2	450/750		-	4-37	4-37	4-37	4-37	4-19	4-19	4-10
KVV22 / KVVP2-22	450/750		-	7-37	7-37	7-37	4-37	4-19	4-19	4-10
KVV32	450/750		-	19-37	19-37	7-37	7-37	4-19	4-19	4-10
KVVR	450/750			2-37	2-37	2-37	2-37
KVVRP	450/750		-	2-37	2-37	2-37	2-37

Cross-linked Polyethylene Insulated Control Cable

This product is intended for use in control, monitoring, and protection circuits rated at 450/750 kV and below; its mechanical, physical, and electrical properties comply with the requirements specified in the GB/T 9330-2020 standard, *Plastic Insulated Control Cables*.

Operating Characteristics and Key Electrical Performance Specifications

1. Cable installation temperature: >0°C.

2. The maximum permissible long-term operating temperature of the cable conductors is 90°C.

3. Minimum permissible bending radius:

a: For unarmored cables, it shall be no less than 8 times the cable's outer diameter.

b: For cables with armor or copper tape shielding structures, it shall be no less than 12 times the cable's outer diameter.

c: For flexible cables with shielding structures, it shall be no less than 6 times the cable's outer diameter.

4. The finished cable shall withstand an AC voltage withstand test of 3.5 kV at 50 Hz for 5 minutes without breakdown.

5. The DC resistance of the conductors shall comply with the requirements specified in the standard GB/T 3956-2008, *Conductors of Cables*.

Types, Names, and Applications of Cross-linked Polyethylene Insulated Control Cables

No.	Model	Full Name	Application Scenarios
1	KYJV	XLPE Insulated PVC Sheathed Control Cable	For fixed installations indoors, in cable trenches, ducts, etc.
2	KYJVP	XLPE Insulated PVC Sheathed Copper Wire Braided Shielded Control Cable	For fixed installations requiring shielding indoors, in cable trenches, ducts, etc.
3	KYJVP2	XLPE Insulated PVC Sheathed Copper Tape Shielded Control Cable	For fixed installations requiring shielding indoors, in cable trenches, ducts, etc.
4	KYJVP3	XLPE Insulated PVC Sheathed Aluminum-Plastic Composite Tape Shielded Control Cable	For fixed installations requiring shielding indoors, in cable trenches, ducts, etc.
5	KYJV22	XLPE Insulated PVC Sheathed Steel Tape Armored Control Cable	For fixed installations with high mechanical stress indoors, in cable trenches, ducts, direct burial, etc.
6	KYJVP2-22	XLPE Insulated PVC Sheathed Copper Tape Shielded Steel Tape Armored Control Cable	For fixed installations with high mechanical stress and requiring shielding indoors, in cable trenches, ducts, direct burial, etc.
7	KYJV32	XLPE Insulated PVC Sheathed Steel Wire Armored Control Cable	For fixed installations with high mechanical tensile force indoors, in cable trenches, ducts, vertical shafts, etc.
8	KYJY	XLPE Insulated Polyolefin Sheathed Control Cable	For fixed installations with high mechanical tensile force indoors, in cable trenches, ducts, vertical shafts, etc.
9	KYJYP	XLPE Insulated Polyolefin Sheathed Copper Wire Braided Shielded Control Cable	For fixed installations with high mechanical tensile force indoors, in cable trenches, ducts, vertical shafts, etc.
10	KYJYP2	XLPE Insulated Polyolefin Sheathed Copper Tape Shielded Control Cable	For fixed installations with high mechanical tensile force indoors, in cable trenches, ducts, vertical shafts, etc.
11	KYJYP3	XLPE Insulated Polyolefin Sheathed Aluminum-Plastic Composite Tape Shielded Control Cable	For fixed installations with high mechanical tensile force indoors, in cable trenches, ducts, vertical shafts, etc.
12	KYJY23	XLPE Insulated Polyolefin Sheathed Steel Tape Armored Control Cable	For fixed installations with high mechanical tensile force indoors, in cable trenches, ducts, vertical shafts, etc.
13	KYJYP2-23	XLPE Insulated Polyolefin Sheathed Copper Tape Shielded Steel Tape Armored Control Cable	For fixed installations with high mechanical tensile force indoors, in cable trenches, ducts, vertical shafts, etc.
14	KYJY33	XLPE Insulated Polyolefin Sheathed Steel Wire Armored Control Cable	For fixed installations with high mechanical tensile force indoors, in cable trenches, ducts, vertical shafts, etc.

Production Scope

Model Group	Conductor Nominal Cross Section (mm²)	0.75	1.0	1.5	2.5	4	6	10
	No. of Cores
KYJV / KYJVP / KYJY / KYJYOP		2-37	2-37	2-37	2-37	2-19	2-19	2-10
KYJVP2 / KYJVP3 / KYJYYP2 / KYJYYP3		4-37	4-37	4-37	4-37	4-19	4-19	4-10
KYJV22 / KYJY23		7-37	7-37	7-37	4-37	4-19	4-19	4-10
KYJVP2-22 / KYJYYP2-23		19-37	19-37	19-37	7-37	4-19	4-19	4-10
KYJV32 / KYJY33		19-37	19-37	7-37	7-37	4-19	4-19	4-10
